B&K Reference 20 Plus - A;V System Controller Specifications

13258 11/01
77
A/V SYSTEM CONTROLLER SPECIFICATIONS
Audio Specifications Video Specifications
Frequency Response:
5 Hz - 20 kHz,
+
0/
−
0.5dB
Frequency Response:
20 Hz - 10 MHz
±
3dB
Input Sensitivity: 2 V in, 1.5 V reference out Maximum Input Level: 2 V P-P
Maximum Output Level: 3 V rms Maximum Output Level: 2 V P-P
Signal to Noise Ratio: 98 dB CCIR 2 k Weighted
Input Impedance: 50 k Ohms Input Impedance: 75 Ohms
Output Impedance: 221 Ohms Output Impedance: 75 Ohms
Noise Test Reference Level: 46 mV Composite Video Inputs 7
Surround Outputs 8 Composite Video Outputs 5
Audio Analog Inputs 7 SVHS Video Inputs 7
Audio Analog Outputs 4 SVHS Video Outputs 5
Multi Channel Input 5.1 format (Optional)
Digital Inputs coax/optical 6/5
Digital Outputs coax/optical 1/1 (Zone 1)
High/Low Pass Crossover Fc Adjustable 20-200 Hz
High Pass Crossover Slope 6 or 12 dB/Oct
Low Pass Crossover Slope 6, 12 or 24 dB/Oct
Tuner Specifications FM Section Tuner Specifications AM section
Frequency Range: 87.5 - 107.9 MHz Frequency Range: 520 - 1670 kHz
Total Harmonic Distortion: Less than 0.25% Total Harmonic Distortion: Less than 0.3%
Frequency Response 20 Hz - 15 kHz, +1/ -3 dB Sensitivity: 28 dBf
Capture Ratio: 2 dB
IHF (Usable) Sensitivity: 12 dBf
Mono/Stereo Sensitivity: 15 / 35 dBf Sensitivity: 28 dBf
Alternate Channel Selectivity: 65 dB Selectivity: 30 dB
Signal to Noise Ratio: 70 dB, A Weighted
Antenna Input Impedance: 75 Ohms Antenna Input Impedance: 300 Ohms
Processor Specifications Miscellaneous
A/D Conversion 24 Bit 48/96kHz Line voltage: 120/220/240 VAC
D/A Conversion 24 Bit 32/44.1/48/96kHz Power consumption: 30 watts max
Dolby Digital/DTS DSP: Motorola 24 Bit 120 MIPS Replacement fuses: Line -.5 Amp/250 Volt
Dimensions: 17"(w)x10"(d)x3.50"(h
)
Weight: 10 pounds
Upgradeability: A/D & D/A, DSP & digital
receiver
Warranty:
See Limited Warranty
5 years processor
1 year remote
Specifications subject to change without notice
