13258 11/01
34
From Remote From Front Panel Action
1
(PAUSE) or
V
(STOP)
(UP) or
(DOWN) move to Test Tone frequency
2
X
(REW) or
W
(FF)
VOLUME KNOB set to desired frequency
3
(PAUSE) or
V
(STOP)
(UP) or
(DOWN) move to Notch, Bass or Treble adjustments
4
X
(REW) or
W
(FF)
VOLUME KNOB set to desired values
5
repeat 1 - 4 repeat 1 – 4 repeat until desired result is achieved
6
MENU
Ø
MENU
return to SETUP SYSTEM
Setup up the notch filter -
your processor may be set to correct accentuated bass information caused by room
size and speaker positioning. The notch filter setup is independent of any other EQ settings and is engaged at all
times, regardless of the EQ selection.
From Remote From Front Panel Action
1
(PAUSE) or
V
(STOP)
(UP) or
(DOWN) move to Notch Frequency
2
X
(REW) or
W
(FF)
VOLUME KNOB set to desired notch frequency
3
(PAUSE) or
V
(STOP)
(UP) or
(DOWN) move to Notch Level
4
X
(REW) or
W
(FF)
VOLUME KNOB set to desired notch level
5
(PAUSE) or
V
(STOP)
(UP) or
(DOWN) move to Notch Width
6
X
(REW) or
W
(FF)
VOLUME KNOB set to desired notch width
7
repeat 1 - 6 repeat 1 – 6 repeat until bass accentuation is reduced
8
MENU
Ø
MENU
return to SETUP SYSTEM
SETUP ROOM EQUALIZATION
Test Tone 100.0 Hz Off
Notch 100.0 Hz 0.0 dB
Notch Width 97.6 - 102.4 Hz
Bass 100.0 Hz 0.0 dB
Treble 10.0 kHz 0.0 dB
next item adjust
MENU setup system
  
100.0 Hz
