NanoRam
®
Series Handheld Raman
19 Shea Way, Newark, DE 19713, USA Tel: +1 (302) 368-7824 Fax: +1 (302) 368-7830 Web: www.bwtek.com
290020255-J (2017/07/28) Page 22 of 38 Copyright 2017 B&W Tek
Using the Right Angle Adapter (optional)
Slide the adapter all the way in with the locating notch aligned with the location pin on the
NanoRam Mini measurement port. Carefully rotate as needed to align the adaptor for
proper positioning. During measurement operations, place the NanoRam Mini so that its
right angle adapter port is in contact with the sample surface.
2.7. Barcode Scanner Key
The barcode scanner functions only in the appropriate displays screens when the system
is in the Identification mode, Investigation mode, or while creating new methods.
To scan the barcode, place the object in front of the barcode scanner at a distance of ~40
-245 mm, depending on the type of barcode. Press the barcode scanner key for at
least 1 second to scan the barcode.
2.8. Laser Switch /Acquisition Key
To turn on the laser, press the laser switch key .
