1. Diagrams of the Instruments
1.1. NanoRam
Laser emission indicator
12V DC Power connector
Ethernet Port
Remote Interlock
Battery compartment
Barcode scan key
Home key
Power On/Off key
Laser emission aperture
/Sampling port
Laser
switch/Acquisition
key
Rubber Protection
