NanoRam
®
Series Handheld Raman
19 Shea Way, Newark, DE 19713, USA • Tel: +1 (302) 368-7824 • Fax: +1 (302) 368-7830 • Web: www.bwtek.com
290020255-J (2017/07/28) Page 5 of 38 Copyright 2017 B&W Tek
The laser hazard zone is within 30cm (11.8 inches) to the tip of the point-and-shoot
adaptor.
1.3. Remote Interlock (for NanoRam only)
The remote interlock is located at the bottom of the unit next to the Ethernet port.
The remote interlock facilitates the laser ‘on’ and ‘off’ remote control function. When the
laser stop key is inserted into the slot, the interlock is closed and laser emission is enabled.
When the key is pulled out, the interlock is open and the laser does not emit and cannot
be turned on.
1.4. Laser Warning Label
The laser warning label is located on the rear panel of the system. The label displays the
laser safety class, wavelength and power of the laser source.
