© 2012 – Banshee Helicopters GmbH Page 20
Fit the RC-unit into the chassis. Use 6 cylinder head bolts hex M3 x 6
(B-S35)
. Do not
necessarily use Loctite to fasten since you need to unscrew the bolts when mounting
the RC-equipment later on. Slide the swashplate onto the main rotor shaft. Then
place it with the ball stud with pin into the swashplate antirotation bracket. Screw it
with two cylinder head bolts hex M3 x 8
(B-S36)
to the elevator servo mounting.
