Display
End Voltage
12.6V(3S)
You can inquire various information on LCD screen during charging or discharging process. When
you press button the charger shows the establishment of user settings. And also you can
monitor the voltage of individual cell by pressing button when the individual connection cable
is linked to the Lithium battery being processed.
The final voltage will be reached at the end of process.
The external temperature only will be displayed when
using the thermal probe.
The present voltage of input power.
Various information during the process
DEC
◀
INC
▶
DEC
◀
Display
Capacity Cut-Off
ON 5000mAh
Display
Safety Timer
ON 200min
Display
Display
Ext. Temp 26C
Display
IN Power Voltage
12.56V
Using the individual connection cable to the battery, you
can check the individual voltages of each cell in the
battery pack. When connect the cable to the port on the
right side of the charger the program shows the voltage
of each cells for maximum 6 cells in sequence. To utilise
this feature, the battery pack must have output
connector that linked to each cells.
Display
4.14 4.16 4.09
0.00 0.00 0.00
DEC
◀
DEC
◀
DEC
◀
DEC
◀
- 18 -
The 3-pin port is assigned as an USB port.
USB/Temp Select
USB Enabled
