Maximum circuit power chart
Maximum charge/discharge current at 12V DC input
No. of cells Nominal voltage(V) Charge current(A) Discharge current(A)
NiCd/NiMH 1 1.2 5.0 1.0
2 2.4 5.0 1.0
3 3.6 5.0 1.0
4 4.8 5.0 1.0
5 6.0 5.0 0.8
6 7.2 5.0 0.7
7 8.4 5.0 0.6
8 9.6 5.0 0.5
9 10.8 4.6 0.5
10 12.0 4.2 0.4
11 13.2 3.8 0.4
12 14.4 3.5 0.3
13 15.6 3.2 0.3
14 16.8 3.0 0.3
15 18.0 2.8 0.3
LiPo 1S 3.7 5.0 1.0
2S 7.4 5.0 0.7
3S 11.1 4.5 0.5
4S 14.8 3.4 0.3
5S 18.5 2.7 0.3
6S 22.2 2.3 0.2
LiIo 1S 3.6 5.0 1.0
2S 7.2 5.0 0.7
3S 10.8 4.6 0.5
4S 14.4 3.5 0.3
5S 18.0 2.8 0.3
6S 21.6 2.3 0.2
LiFe 1S 3.3 5.0 1.0
2S 6.6 5.0 0.8
3S 9.9 5.0 0.5
4S 13.2 3.8 0.4
5S 16.5 3.0 0.3
6S 19.8 2.5 0.3
For the voltage of battery is more than 10V, the actual amount of charge current delivered to the
battery might automatically be limited so not to exceed the charger's maximum rated charging
power of 50 watts. And also, for the battery having more than 5V, the discharge current delivered
to the battery might be limited by the maximum rated discharge power of 5 watts. The actual
feeding current will be as follows;
