4780 0318
BARBER SURF RAKE
®
MODEL 400
SECTION 4 – MAINTENANCE
To prevent injury, before conducting any repair or maintenance on the Surf Rake
®
, ensure that
the hydraulic pump is OFF, not just in neutral, and examine the machine carefully to assure
that:
No hydraulic hoses remain pressurized
No parts of the machine are suspended without being mechanically blocked or supported.
All sources of power have been locked in the “off” position and tagged.
Follow OSHA regulations regarding hydraulic fluid, fire safety, guarding and, if applicable,
lock-out/tag-out procedures.
Always ensure that the parking brake on the tractor is set before working on the Surf Rake
®
to
prevent injury.
Never modify any part of the Surf Rake
®
without prior approval, in writing, from H. Barber &
Sons, Inc. Do not replace any component of the Surf Rake
®
with one that is not manufactured
by Barber or listed in this manual as a proper replacement part.
LUBRICATION
GREASE FITTINGS Lubricate all grease fittings every 40 hours of operation. (See Maintenance
and Lubrication Chart - Section 5)
CHAINCASE ROLLER CHAIN Roller Chain should be oiled after every 100 hours of use.
TURNBUCKLES The Turnbuckles should be cleaned and re-greased at the end of the season. In
severe rusting areas this should be done more frequently.
PINS Cylinder and moldboard pins should be spot lubricated with oil every 4 weeks.
CYLINDERS Cylinder tops should be wiped clean and spot lubricated with penetrating oil every
100 hours and at the end of the season.
CONVEYOR CHAIN It is recommended that the Conveyor Chain be run dry. A dry graphite
lubricant may also be used. Occasionally, especially after a period of disuse, light penetrating oil
may be applied.
Prior to winter storage, heavier oil may be applied to avoid rusting.
