Barber SURF RAKE 400 - Caster Assembly (Option)

4780 0318
OPTIONAL CASTER ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION 400S 0111
1 251A 2 FORK ASSEMBLY
2 251B 12 WASHER
3 509FA 2 LOCKING NUT
4 251C 2 BOLT
5 251D 4 WASHER
6 251E 2 SPACER TUBE
7 251F 4 ROLLER BEARING
8 560B08100 8 BOLT
9 524G 8 LOCK WASHER
10 251G 2 WHEEL FLANGE AND TIRE ASSEMBLY
11 251H 2 HUB ASSEMBLY
12 251ASY 2 CASTER ASSEMBLY COMPLETE
13 251JASY 2 CASTER HOLDER
14 251N 2 SNAP PIN
15 524D 8 CAPSCREW
16 524G 8 LOCK WASHER
17 523R 8 HEX NUT
18 251TB05 4 SPACER
19 603GG 8 FLAT WASHER
20 251AS01 2 RETAINER CAP ASSEMBLY
21 251TCM07 2 SPRING
22 560B05100E 2 EYEBOLT
23 560N05L 4 NUT
