4780 0318
MOLDBOARD AND SHIELDS
ITEM PART NUMBER QTY DESCRIPTION 400S 0719
1 422AS01 1 MOLDBOARD
2 560N08L 4 LOCK NUT
3 560B08100 4 CAPSCREW
4 524X 14 CAPSCREW
5 560B05075 11 CAPSCREW
6 560N05L 14 LOCK NUT
7 522JT 2 TURNBUCKLE
8 522JT1 4 PIN
9 522JT2 4 COTTER PIN
10 442A/B 2 SIDE SHIELD (B SHOWN)
11 409D 2 CAPSCREW
12 502N 16 FLAT WASHER
13 509FA 2 LOCKING NUT
14 424F 1 BACK SHIELD
15 424E 1 BACK FLAP
16 424G 1 BACK FLAP HOLD DOWN
17 A425 1 BUCKET
18 545NN 4 PIN
19 530CM06 2 PIN
20 502P 6 COTTER PIN
21 524S 25 FLAT WASHER, STAINLESS
22 442E 2 SIDE GUARD FLAP HOLD DOWN
23 442F 2 SIDE GUARD FLAP
24 442G 1 TOP CONVEYOR SHIELD
25 603GG 4 FLAT WASHER
26 524Y 11 LOCK WASHER
27 422TB02 2 SPACER
28 509C 2 WASHER
29 422F 1 MOLDBOARD FLAP
30 422G 1 MOLDBOARD FLAP HOLD DOWN BAR
6-3
