4780 0318
DRIVE MECHANISM
ITEM PART NUMBER QTY DESCRIPTION 400S 0118
1 435AS01 1 SPROCKET AND SHAFT ASSEMBLY
2 436AS01 1 SPROCKET AND SHAFT ASSEMBLY
3 540D 2 CAPSCREW
4 403T 4 BEARING
5 408BB 8 CAPSCREW
6 524G 8 LOCK WASHER
7 523R 8 HEX NUT
8 503ZE01 2 GREASE FITTING
9 560B06100 4 CAPSCREW
10 549AS08 4 IDLER ROLLER ASSEMBLY
11 549AS01 4 PIN AND BASE ASSEMBLY
12 549CM01 4 SEAL
13 527GF-2 8 ROLLER BEARING
14 527GF-9 8 RACE
15 549CM08 4 IDLER ROLLER
16 549CM03 4 SNAP RING – SMALL EXTERNAL
17 560B06125 4 CAPSCREW
18 509H 8 LOCK WASHER
19 549CM05 8 SHIM
20 603GG 12 WASHER
21 503VV 2 BEARING
22 A440G 2 TAKE UP BOLT
23 560N08L 8 LOCK NUT
24 549AS04 2 SPROCKET ROLLER ASSEMBLY
25 503ZE01 4 GREASE FITTING
26 549FM02 4 COVER PLATE WITH HOLE
27 549FM01 4 COVER PLATE
28 549CM02 8 SNAP RING – LARGE INTERNAL
29 503CAP 8 GREASE COVER
30 560B08100 2 CAPSCREW
31 449AS01 2 SPROCKET MOUNTING BRACKET
6-4
