4780 0318
CONVEYOR
ITEM PART NUMBER QTY DESCRIPTION 400S 0111
1 504FH 320 TINE
2 410HA 10 CHANNEL A WITH STUDS AND WASHERS
3 410HB 10 CHANNEL B WITH STUDS AND WASHERS
4 404BE02 1 BELT
5 404DK 1 OFFSET CHAIN, COMPLETE (BOTH SIDES)
6 504G 40 CAPSCREW
7 560W06S 40 WASHER
8 560W06H 42 SPACER, SILVER
9 504H 40 LOCKNUT
10 560N05LS 320 LOCKNUT
11 560W05S 640 WASHER
12 504DKSL OFFSET CHAIN SEGMENT, LEFT SIDE
13 504DKSR OFFSET CHAIN SEGMENT, RIGHT SIDE
14 404DB CHAIN PIN AND COTTER
15 560B05095S 320 STUD
16 510HC 40 SPACER
17 504CM02 CHANNEL STUD REPLACEMENT TOOL
18 404AS02 CONVEYOR ASSEMBLY COMPLETE (NOT SHOWN)
