Barber SURF RAKE 400 - Sprocket Roller Assembly

4780 0318
SPROCKET ROLLER ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION 400S 0118
1
549CM02
2
SNAP RING, LARGE INTERNAL
2
549FM01
1
FRONT COVER PLAET
3
549CM03
1
SNAP RING, SMALL EXTERNAL
4
527GF
-
2
2
ROLLER BEARING
5
527GF
-
9
2
RACE
6
549AS04
1
SPROCKET
ROLLER ASSEMBLY, COMPLETE
7
549CM01
1
SEAL
8
549FM02
1
REAR COVER PLATE
9
549AS01
1
PIN AND BASE ASSEMBLY
10
549CM05
2
SHIM
11
503CAP
1
GREASE COVER
12
503ZE01
1
GREASE FITTING
6-5
