Barco CX-30 User Manual

37R5900098 /10 CX-30
Context menu
1. Click on the menu icon on the Ready to share message.
Image 3–26
The context menu appears.
2. From the list, click the action you want to perform.
3.9 Extended desktop
About extended desktop
Depending on your selection, your primary screen or your extended screen will be captured and displayed via
ClickShare. That extended screen can be a physical screen or a virtual screen.
The use of the extended desktop functionality does require the extension pack to be installed on your device.
More information on the extension pack can be found on the ClickShare Extension pack product page (https://
www.barco.com/en/product/clickshare-extension-pack).
With extended desktop you can take advantage of both your laptop screen and the central meeting room
display. Presentation notes or other material on primary screen will not be displayed to everyone (so-called
PowerPoint Presenter mode) or when you want to take notes whilst sharing something else..
Note that the Presenter mode can also be achieved without the use of the extended desktop and one can also
choose to share only the application you wish to share in the room via the sharing mode toggle (see “Share an
application”, page 38).
PC with virtual extended screen:
1
2
Image 3–27
Primary screen displayed on the PC, extended screen displayed on the meeting room display.
Getting started

Barco CX-30 Specifications

General

Warranty period	1 year(s)
Sustainability compliance	Yes
Sustainability certificates	CE, Federal Communications Commission (FCC)
Form factor	Desktop
Product color	Black
Cable lock slot type	Kensington
Input voltage	110 - 220 V
Power source type	AC
Power consumption (max)	24 W
Power consumption (typical)	10 W
Mac operating systems supported	Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Mobile operating systems supported	Android 9.0, iOS 12, iOS 13
Windows operating systems supported	Windows 10, Windows 8, Windows 8.1
Supported graphics resolutions	3840 x 2160
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	0 - 85 %
Frequency band	2.4, 5 GHz
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA2-PSK
Interface	HDMI
HDMI version	1.4b
Number of HDMI outputs	1

Weight and Dimensions

Width	135 mm
Height	34 mm
Weight	900 g
