Lens focus
Press the button on the remote control or MENU on the projector panel, Choose OSD -> LENS FOCUS , then use the
buttons to adjust the lens' focus (clarity).
—>
Lens zoom
Press the button on the remote control or MENU on the projector panel, Choose OSD -> LENS ZOOM , then use the
buttons to adjust the size of the image that is projected onto the screen.
Original image size
Zoom out Zoom in
Lens Shift
In addition to using the adjustable feet to adjust projection angle, you can also use the Lens Shift function to adjust the
projected image.
•
Moving the lens vertically
The distance of vertical lens movement is +100% , -30% of half the screen height in both directions.For instance, if you are
using a 80" × 50" screen, you will be able to move the image upwards no more than 27.5'' or downwards no more than
17.5''.
lens shift
adjustment
This illustration shows normal vertical
lens shift without the use of special
specification lens or projector.
