Barco Nio 3MP - 6 Repackaging Instructions

6. Repackaging instructions
6. REPACKAGING INSTRUCTIONS
WARNING: Before repacking the display, follow the instruction to replace the protection
buffer to prevent damage to the display.
Overview of the packaging
1
2
3
4
5
6
7
8
Image 6-1
Packaging
1
Bottom box
5
Box (Power supply, cables)
2
Bottom buffer
6
Top b uff e r
K5902067 NIO 3MP LED DISPLAY 26/11/2014
33
