8. Important information
Net weight w/o stand
8kg
Net weight packaged with
stand
17,7 kg
Net weight packaged w/o stand N/A
Height adjustment range 100 mm
Tilt
-5° / +25°
Swivel -30° / +30°
Pivot
N/A
Mounting standard
VESA (100 mm)
Screen protection Protective, non-reflective glass cover
Recommended modalities
CT, MR, US, DR, CR, NM, Film
Certifications CE0120 (MDD 93/42/EEC; A1:2007/47/EC class IIb product), CE
- 2004/108/EC, CE - 93/42/EEC; A1:2007/47/EC class II b, IEC
60950-1:2005 + A1:2009 (2ND EDITION), IEC 60601-1:2005 + A1:2012,
ANSI/AAMI ES 60601-1:2005 + C1:2009 + A1:2012, CAN/CSAC22.2
No. 60601-1-08:2008, DEMKO - EN 60601-1:2006, EN 60601-1-2:2007,
CCC - GB9254-2008 + GB4943.1-2011 + GB17625.1-2003, KC, VCCI,
FCC class B, ICES-001 Level B, FDA 510(k), RoHS
User Guide
Quick Installation Sheet
Video cables (1 x DVI Dual Link + 1 x DisplayPort)
Main cables (UK, European (CEBEC/KEMA), USA (UL/ CSA; adaptor
plug NEMA 5-15P), Chinese (CCC))
USB 2.0 cable
Supplied accessories
External power supply
Optional accessories
None
QA software MediCal QAWeb
Units per pallet NA
Pallet dimensions (W x H)
NA
Warranty
5years
Operating temperature 0°C to 40°C (15°C to 30°C within specs)
Storage temperature -20°C to 60°C
Operating humidity 8% - 80% (non-condensing)
Storage humidity 5% - 95% (non-condensing)
Operation altitude
2000 m
Storage altitude
7500 m
8.8 Open source license information
Open source license information
Open source license usage
This product contains software components released under an Open Source license. A copy of the source
code is available on request by contacting your Barco customer support representative.
EACH SEPARATE OPEN SOURCE SOFTWARE COMPONENT AND ANY RELATE D DOCUMEN TA-
TION ARE PROVIDED "AS IS" WITHOUT EXPRESS OR IMPLIED WARRANTY INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICU-
LAR PURPOSE. IN NO EVENT SHALL THE COPYRIGHTHOLDER OR ANY OTHE R CONTRIBUTOR
K5902067 NIO 3MP LED DISPLAY 26/11/2014
51
