Instructions for Use
Barkey S-line
2.1 Components of the Barkey S-line
1
.
Control unit
Controls the temperature in the warming section.
2
.
Warming section
The flexible warming section holds the infusion
tube and transmits the heat to the flowing fluid.
3.
Warming section
holder
The warming section can be placed at its head
and end in the holder provided. This prevents
unintentional contact with the floor.
4
.
Fastening clamp
The fastening clamp fixed to the back of the
housing is used to fasten the Barkey S-line to an
infusion stand.
5.
Power cable
Transmits electricity from the socket to the
warming device.
Fig. 2: Barkey S-line
4
3
2
1
5
