page 24
295 AC
800-00158
SPECIAL TORQUE SPECIFICATIONS
LUBRICATE WITH ANTI-SEIZE COMPOUND PART NO. 514-00700
Swing Motor Mounting Bolts ......................................................................... 64 Ft. Lbs.
Swing Motor Gearbox Mounting Bolts ........................................................... 310 Ft. Lbs.
Turntable Bearing Bolts (Do not re-use old bolts/nuts.) ................................ 500 Ft. Lbs.
Valve Bank Nuts:
To be tightened in three steps:
1. Tighten all nuts in a clockwise pattern to:
2. Tighten all nuts in a clockwise pattern to:
3. Tighten all nuts in a clockwise pattern to:
K170 Upper
Valve Bank
(Ft. Lbs)
11
30
44
L90 Lower
Valve Bank
(Ft. Lbs.)
7
21
33
Other torques, for the valves, pumps, and motors are found in the service literature for those components.
WARNING
Loose or overtorqued bolts can cause death,
severe injury, or property damage. Maintain
proper bolt torque. Visually check bolts daily.
Check torque every 50 hours.
WARNING
In critical applications (such as Turntable Bearing
Bolts and any grade 8 or grade 9 bolts), once the
old bolts and nuts have been loosened, they must
be replaced rather than re-tightened and re-
torqued. Original clamping force cannot be
achieved using the old bolts and nuts.
