ABBREVIATIONS AND SYMBOLS
EXPLANATIONS OF OTHER OCCURRENCES IN THIS MANUAL:
- In a parts list, when there are item numbers with empty spaces (no description or part number), these
parts have been previously deleted from that parts list and are not recorded anywhere.
- In a parts list, when there are items with no part number and a dotted line (----) is in the part number
space, this means that the part number is not sold separately or is not available at this time.
- When references to "right hand" or "left hand" are used in this manual, it is done from the operator's seat
in the forward operating position.
SYMBOLS USED ON MACHINE
Ignition
Key Switch
Power On
(Accessory)
Power Off
Power On
Horn
Starter
Engine
RPM
Faster
Slower
Air
Conditioner
a/c = air conditioner
AC = Articulated Carrier (Art. Car.)
adj. = adjust or adjusting
appl. = application
AR = As Required
assy = assembly
BC = Back of Cab
b/m = bill of material
brg. = bearing
CAR = Carrier
coll. = collector
cond. = conditioner
CRL = Crawler
cyl. = cylinder
dia. = diameter
dwg. = drawing
Ft. Lbs. = Foot Pounds
gal. = gallon
HRT = Hydrostatic Rough Terrain carrier
ill. or illus. = illustration
In. Lbs. = Inch Pounds
incl. = includes or including
j.s. = joystick
Lbs. = pounds
LH (lh) = left hand
mtg. = mounting
N/A = Not Applicable
no. = number
NSS = Not Sold Separately
opt. = optional
pg. = page
qt. = quart
RH (rh) = right hand
sec. = secondary
see sep. ill. = see separate illustration (means:
located elsewhere in manual)
SE = Stationary Electric
SER or SR = Stationary Electric Remote
s/n = serial number
str. = straight
swhd = saw head
TM = Truck Mount
w/ = with
