page 56
295 AC
800-00158
Battery does not hold it's charge.
Alternator will not charge.
Starter will not turn the engine.
PROBLEM
CAUSE
1, 2, 3, 4, 5
1, 2, 5
2, 3, 4, 6, 7, 8
KEY TO CORRECT THE CAUSE
1. Alternator belt is loose or damaged.
2. Battery connections are dirty of loose.
3. Battery is damaged.
4. The ground connection is not making a good contact.
5. The alternator is damaged.
6. The engine is locked.
7. The starter has damage.
8. The wiring or the solenoid is damaged.
TROUBLE SHOOTING THE ELECTRICAL SYSTEM
The following trouble shooting chart is provided as an assistance in locating and correcting problems which are
most common.
ELECTRICAL SYSTEM MAINTENANCE CONTINUED...
