240 Harvester Feller/
Buncher
The following tables contain information about the different possible failures that could occur for each module
subsystem. In most cases when an error is detected, a message will be presented on the master display together with
an error code on the module. In some cases, the module will turn off or at least shut down the outputs, to increase
safety.
IQAN XS2IQAN XS2
IQAN XS2IQAN XS2
IQAN XS2
FAILURE MODEFAILURE MODE
FAILURE MODEFAILURE MODE
FAILURE MODE
1 +VREF Open VIN out of range, will create a VIN error =>
VIN=Predefined error value. (a)
2 -VREF Open VIN out of range, will create a VIN error =>
VIN=Predefined error value. (a)
3 +VREF Short-circuit to -VREF VREF error => VIN out of range, will create a VIN
error => VIN=Predefined error value. (a)
4 +VREF Short-circuited to +BAT VREF error => VIN out of range, will create a VIN
error => VIN=Predefined error value. (a)
5 +VREF Short-circuited to -BAT VREF error => VIN out of range, will create a VIN
error => VIN=Predefined error value. (a)
6 -VREF Short-circuited to +BAT External fuse (if <7.5A) on +BAT blows.
7 -VREF Short-circuited to -BAT Not detected.
1 CAN-H to -BAT No CAN communication. All output turned off.
2 CAN-L to -BAT No CAN communication. All output turned off.
3 CAN-H to +BAT No CAN communication. All output turned off.
4 CAN-L to +BAT No CAN communication. All output turned off.
5 CAN-L open circuit No CAN communication. All output turned off.
6 CAN-H open circuit No CAN communication. All output turned off.
7 CAN-L to CAN-H No CAN communication. All output turned off.
8 CAN-termination failure, termination on No effect
9 CAN-termination failure, termination off Dependent on CAN size and number of CAN nodes.
