Barnes 3SHV - Page 12

12
MODEL
NO
HP VOLT PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
MAIN - - START
4SHVBA Pump
4SHVBA5074* 5.0
208
1 60 1750
D 27.2 1.2 35.6 99.9 125498 8/4 - 18/4 1.12 ± .02 0.50 - 2.66
230 F 25.4 1.2 30.2 112.4 125496 12/4 - 18/4 .86 ± .02 0.50 - 2.66
4SHVBA50N4* 5.0
208
3 60 1750 J
15.8 1.2 18.7 82.4 125496 12/4 - 18/4 .86 ± .02 0.72
230 15.0 1.2 17.2 92.4 125496 12/4 - 18/4 .86 ± .02 0.72
460 7.5 1.2 8.6 46.2 125497 12/4 - 18/4 .86 ± .02 2.88
4SHVBA5054* 5.0 575 3 60 1750 J 6.0 1.2 6.9 37.0 125497 12/4 - 18/4 .86 ± .02 4.32
4SHVBA75N4 7.5
208
3 60 1750 H
23.8 1.2 28.5 105.9 125496 12/4 - 18/4 .86 ± .02 0.43
230 23.7 1.2 27.2 123.6 125496 12/4 - 18/4 .86 ± .02 0.43
460 11.9 1.2 13.6 61.8 125497 12/4 - 18/4 .86 ± .02 1.72
4SHVBA7554 7.5 575 3 60 1750 H 9.5 1.2 10.9 49.4 125497 12/4 - 18/4 .86 ± .02 2.69
4SHVBA100N4 10.0
208
3 60 1750 E
32.2 1.2 41.4 105.9 125498 8/4 - 18/4 1.12 ± .02 0.43
230 29.8 1.2 35.6 123.6 125498 8/4 - 18/4 1.12 ± .02 0.43
460 14.9 1.2 17.8 61.8 125497 12/4 - 18/4 .86 ± .02 1.72
4SHVBA10054 10.0 575 3 60 1750 E 11.9 1.2 14.2 49.4 125497 12/4 - 18/4 .86 ± .02 2.69
Moisture and Temperature sensor leads are integral to power cord. Winding Resistance ± 7.5% Winding resistance measured in OHMS @ 25°C (Between Lines) at motor leads. Pump rated for operation at ± 10% voltage at motor. ▲ Cord Sufx: XC - 30 Feet, XF - 50 Feet, XJ - 75 Feet, or XL - 100 Feet
▲ Cord sold separately. * Select impeller diameter when ordering.
Single Phase pumps require start components to be included in panel. Provided with pump.
CHART ‘G’
