Barnes 3SHV - IMPELLER SPECIFICATIONS; Impeller Specifications and Part Numbers

28
“C” Impeller– Monovane
Trim Dia.
mm (in)
Ductile Iron
Part No.
Nihard
Part No.
235mm (9.25in) 127263 143276
230mm (9.06in) 127263TA 143276TA
225mm (8.86in) 127263TB 143276TB
220mm (8.66in) 127263TC 143276TC
215mm (8.46in) 127263TD 143276TD
210mm (8.27in) 127263TE 143276TE
205mm (8.07in) 127263TF 143276TF
200mm (7.87in) 127263TG 143276TG
195mm (7.68in) 127263TH 143276TH
190mm (7.48in) 127263TJ 143276TJ
185mm (7.28in) 127263TK 143276TK
“A” Impeller– Vortex
Trim Dia.
mm (in)
Ductile Iron
Part No.
Nihard
Part No.
205mm (8.07in) 125454B 143272B
200mm (7.87in) 125454BTA 143272BTA
195mm (7.68in) 125454BTB 143272BTB
205mm (8.07in) 125454 143272
200mm (7.87in) 125454TA 143272TA
195mm (7.68in) 125454TB 143272TB
190mm (7.48in) 125454TC 143272TC
185mm (7.28in) 125454TD 143272TD
180mm (7.09in) 125454TE 143272TE
175mm (6.89in) 125454TF 143272TF
170mm (6.69in) 125454TG 143272TG
165mm (6.50in) 125454TH 143272TH
160mm (6.30in) 125454TJ 143272TJ
155mm (6.10in) 125454TK 143272TK
150mm (5.91in) 125454TL 143272TL
145mm (5.71in) 125454TM 143272TM
140mm (5.51in) 125454TN 143272TN
135mm (5.31in) 125454TP 143272TP
130mm (5.12in) 125454TR 143272TR
125mm (4.92in) 125454TS 143272TS
“B” Impeller– Vortex
Trim Dia.
mm (in)
Ductile Iron
Part No.
Nihard
Part No.
185mm (7.28in) 125456 143273
180mm (7.09in) 125456TA 143273TA
175mm (6.89in) 125456TB 143273TB
170mm (6.69in) 125456TC 143273TC
165mm (6.50in) 125456TD 143273TD
160mm (6.30in) 125456TE 143273TE
155mm (6.10in) 125456TF 143273TF
150mm (5.91in) 125456TG 143273TG
145mm (5.71in) 125456TH 143273TH
140mm (5.51in) 125456TJ 143273TJ
135mm (5.31in) 125456TK 143273TK
130mm (5.12in) 125456TL 143273TL
125mm (4.92in) 125456TM 143273TM
120mm (4.72in) 125456TN 143273TN
115mm (4.53in) 125456TP 143273TP
110mm (4.33in) 125456TR 143273TR
105mm (4.13in) 125456TS 143273TS
100mm (3.94in) 125456TT 143273TT
95mm (3.74in) 125456TU 143273TU
“F” Impeller
Trim Dia.
mm (in)
Ductile Iron
Part No.
Nihard
Part No.
190mm (7.48in) 133052 143277
185mm (7.28in) 133052TA 143277TA
180mm (7.09in) 133052TB 143277TB
175mm (6.89in) 133052TC 143277TC
170mm (6.69in) 133052TD 143277TD
165mm (6.50in) 133052TE 143277TE
160mm (6.30in) 133052TF 143277TF
155mm (6.10in) 133052TG 143277TG
150mm (5.91in) 133052TH 143277TH
145mm (5.71in) 133052TJ 143277TJ
140mm (5.51in) 133052TK 143277TK
135mm (5.31in) 133052TL 143277TL
130mm (5.12in) 133052TM 143277TM
125mm (4.92in) 133052TN 143277TN
“G” Impeller
Trim Dia.
mm (in)
Ductile Iron
Part No.
Nihard
Part No.
235mm (9.25in) 129991 143204
230mm (9.06in) 129991TA 143204TA
225mm (8.86in) 129991TB 143204TB
220mm (8.66in) 129991TC 143204TC
215mm (8.46in) 129991TD 143204TD
210mm (8.27in) 129991TE 143204TE
205mm (8.07in) 129991TF 143204TF
200mm (7.87in) 129991TG 143204TG
195mm (7.68in) 129991TH 143204TH
190mm (7.48in) 129991TJ 143204TJ
185mm (7.28in) 129991TK 143204TK
180mm (7.09in) 129991TL 143204TL
175mm (6.89in) 129991TM 143204TM
170mm (6.69in) 129991TN 143204TN
165mm (6.50in) 129991TP 143204TP
“S” Impeller
Trim Dia.
mm (in)
Ductile Iron
Part No.
Nihard
Part No.
200mm (7.87in) 133044 143287
195mm (7.68in) 133044TA 143287TA
190mm (7.48in) 133044TB 143287TB
185mm (7.28in) 133044TC 143287TC
180mm (7.09in) 133044TD 143287TD
175mm (6.89in) 133044TE 143287TE
170mm (6.69in) 133044TF 143287TF
165mm (6.50in) 133044TG 143287TG
160mm (6.30in) 133044TH 143287TH
155mm (6.10in) 133044TJ 143287TJ
