Barnes 3SHV - PUMP KITS AND COMPONENTS; Rotor Kit Contents; Stator;Motor Housing Kit Contents; Motor Kit Contents

32
3450 RPM
Model No.
Rotor Kit
Part No.
Stator / Motor Housing
Kit Part No.
─ SH ─ ─ 5072 133927 133928
─ SH ─ ─ 50N2 133929 133930
─ SH ─ ─ 5052 133931 133932
─ SH ─ ─ 75N2 133933 133934
─ SH ─ ─ 7552 133935 133936
─ SH ─ ─ 100N2 138722 133938
─ SH ─ ─ 10052 133939 133940
─ SH ─ ─ 3052 138641 138642
1750 RPM
Model No.
Rotor Kit
Part No.
Stator / Motor Housing
Kit Part No.
─ SH ─ ─ 2074 133941 133942
─ SH ─ ─ 2054 133945 133946
─ SH ─ ─ 3074 133947 133948
─ SH ─ ─ 3054 133951 133952
─ SH ─ ─ 5074 133953 138735
─ SH ─ ─ 5054 133957 133958
─ SH ─ ─ 7554 133961 133962
─ SH ─ ─ 10054 138721 138730
1750 RPM
Model No. Motor Kit Part No.
─ SH ─ ─ 20N4 145660
─ SH ─ ─ 30N4 145663
─ SH ─ ─ 50N4 145666
─ SH ─ ─ 75N4 145668
─ SH ─ ─ 100N4 145670
Example
Model No.
Rotor Kit
Part No.
Stator /
Motor Housing
Kit Part No.
4SHMS75N4 138729 138738
Rotor Kit includes:
• Lower Shaft Snap Ring
• Upper Shaft Snap Ring
• Rotor
Additional Components
Component Part No. Single Sale Kit
Impeller See Table Yes N/A
Wear Ring See Table Yes Volute Kit
Lifting Handle 133032 Yes N/A
Pipe Plugs 014270-SS Yes Seal Plate Kit, Stator Kit
Wire Tie Cable 039462 Yes Stator Kit
Nameplate No Resale
Nameplate/Model Plate Rivets 001628 No Resale Rivet Kit (p/n 139398)
Driver Assembly
Purchase:
Stator Kit, Rotor Kit, Seal Kit, Bearing Kit, Bearing Bracket Kit,
Hardware Kit, Seal Plate Kit, Terminal Block Kit
OR
Motor Kit, Seal Plate Kit, Hardware Kit
Overhaul Kit Purchase Seal Kit and Hardware Kit
Stator/Motor Housing Kit includes:
• Motor Housing (painted)
• Pipe Plug
• Set Cap Screw
• Stator
• Self-clinching Tie Cable
• Cap Plug
Motor Kit includes:
• Lower Shaft Snap Ring
• Upper Shaft Snap Ring
• Rotor
• Motor Housing (Painted)
• Pipe Plug
• Set Cap Screw
• Stator
• Self-Clinching Tie Cable
• Cap Plug
• Terminal Block Kit
• Moisture Sensor Kit
• Bearing Bracket Kit
• Bearing Kit
* Motor kits ship pre-assembled
