3
DISCHARGE ....................... 2” NPT (M), Vertical
LIQUID TEMPERATURE .... 104°F (40°C) Max.
VOLUTE .............................. Non-Metallic
MOTOR SHELL .................. Stainless Steel
IMPELLER .......................... Non-Matallic
SHAFT ................................. 420 Stainless Steel
HARDWARE ....................... 300 Series Stainless Steel
SEAL Design ............. Tandem Mechanical, Oil-Filled
Reservoir
Material:
Stationary Face.Silicon/Carbide, Pump End
Ceramic, Motor End
Rotating Face ...Carbon
Elastomer .........Buna-N
Hardware ..........300 series stainless steel
CORD ENTRY ..................... 50 Ft. (15m) Cord with Plug on 120
Volt. Molded for strain relief and
compression seal
SPEED ................................ 3450 RPM (Nominal)
MOTOR: Design ............. NEMA Design L-Single Phase,
Air-Filled, Squirrel Cage Induction
Insulation ........ Class F
SINGLE PHASE .................. Capacitor Start and Run
Includes Overload protection in motor
LIFTING ROPE ................... 3/8” (9.7mm) Polypropylene,
25 Ft (7.6m)
STRAINER .......................... .25” (6mm) Openings, Non-Metallic
LIFTING HANDLE ............... Non-Matallic
PUMP SPECIFICATIONS:
MODEL NO. BARNES
PART NO.
PROSSER
PART NO.
A - Dim
Inch (mm)
HP VOLT PH HERTZ RPM FULL LOAD
AMPS
70 115070 115165 17.76 (451) 0.7 120 1 60 3450 8.0
71 115071 115166 17.76 (451) 0.7 240 1 60 3450 4.0
125 115125 115167 18.54 (471) 1.25 120 1 60 3450 15.0
126 115126 115168 18.54 (471) 1.25 240 1 60 3450 7.6
inches
(mm)
Plug On 120 Volt Only
IMPORTANT !
1.)
PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN
ACCORDANCE WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT
INTENDED FOR USE IN SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH
PUMPED MEDIA IS A COMMON OCCURRENCE.
