Barnes 70 Series - Parts List; Repair Parts Kits

9
PARTS LIST
ITEM QTY PART NO. DESCRIPTION
1 2 115084 SkHd Screw, M6 x 15, SS
2 2 115085 Flatwasher, 6mm, SS
3 1 115083 Discharge Outlet, 2” NPT
4 1 115086 Discharge Gasket
5 1 115081 Cable Clamp
6 1 115082 Self-Tapping Screw M4.8 x 16, SS
7 1 115078
115079
Cable, w/Plug 120 Volt
Cable w/o Plug 240 Volt
8 2 115131 O-ring 6mm Dia. x 1.9mm
9 2 115130 SkHd Screw M6 x 10, SS
10 1 115124 O-ring 35mm Dia. x 3.1mm
11 8 115138 Flatwasher 5mm, SS
12 1 130825 Mechanical Seal
13 1 115140 Impeller Key, 3mm x 10mm, SS
14 1 115142 Flatwasher 8mm, SS
15 1 115141 Hex Nut, 8mm, SS
16 1 068988 Mechanical Seal
17 2 115106 Snap Ring
18 1 Seal Plate
19 4 115135 RdHd Screw, M5 x 10, SS
20 3 115139 Impeller Shim
21 1 115121
115122
0.7 HP (70 & 71 Series) Impeller
1.25 HP (125 & 126 Series) Impeller
22 1 115143 Lockwasher, 8mm, SS
23 1 115103 O-ring, 170mm Dia. x 2.5mm
24 1 115137 Suction Case
25 1 115145 Suction Strainer
26 4 115144 Screw, M5 x 72, SS
REPAIR PARTS KITS
115073 120 Volt Cord Kit - Items 5, 6 & 7
115074 240 Volt Cord Kit - Items 5, 6 & 7
115075 Discharge Nozzle Kit - Items 1, 2, 3 & 4
115077 Strainer Kit - Items 11, 25 & 26
115072 0.7 HP Impeller Kit - Items 13, 14, 15, 20, 21, 22 & 24
115127 1.25 HP Impeller Kit - Items 13, 14, 15, 20, 21, 22 & 24
115076 Mechanical Seal Kit - Items 8, 9, 10, 11, 12, 16, 17 & 19
Repair parts are available in REP
AIR PARTS KITS ONLY. Each kit contains an instruction sheet with
procedures and illustrations to assist in replacement of the necessary parts
