- 37 -
Combi Steamer 6 x 1/1 GN
Combi Steamer
6 x 1/1 GN, 6 x 600x400
Power: 8,0 kW / 2 NAC 400 V
Size: W 925 x D 760 x H 800 mm
Distance between trays: 80 mm
Weight: 80 kg
Code-No. 116.406
Explanations
X = Incoming water 3/4"
F = Steam outlet 60 mm
B = Electrical feeding
T = Safety thermostat
S = Water drain
Size in mm
