- 36 -
4.2 Technical specification
Combi Steamer 5 x 2/3 GN
Combi Steamer
5 x 2/3 GN
Power: 3,3 kW 220 V
Size: W 610 x D 685 x H 743 mm
Distance between trays: 70 mm
Weight: 50 kg
Code-No. 116.402
Explanations
X = Incoming water 3/4"
F = Steam outlet 25 mm.
B = Electrical feeding
T = Safety thermostat
S = Water drain
Size in mm
