- 39 -
Combi Steamer 10 x 1/1 GN
Combi Steamer
10 x 1/1 GN, 10 x 600x400
Power: 12,0 kW / 3 NAC 380-400 V
Size: W 925 x D 760 x H 1120 mm
Distance between trays: 80 mm
Weight: 110 kg
Code-No. 116.410
Explanations
X = Incoming water 3/4"
F = Steam outlet 60 mm
B = Electrical feeding
T = Safety thermostat
S = Water drain
Size in mm
