DGC-2020ES Configuration through the Front Panel
■ ACTIVATN DLY
■ MIN OHMS
■ MAX OHMS
■ SF DISPLAY
○ FUEL LEVL SENDR FAIL
■ CONFIG TYPE
■ RECOGNITION
■ ACTIVATN DLY
■ MIN OHMS
■ MAX OHMS
■ SF DISPLAY
○ VOLTAGE SENSE FAIL
■ CONFIG TYPE
■ ACTIVATN DLY
○ SPEED SENDR FAIL
■ TIME DELAY
GENERATOR PROTECTION
● 27 UNDERVOLTAGE
○ LOW LINE SF (Visible when an input is selected for the Low Line Override programmable function.)
○ 3 / 1 PHASE SETTINGS
■ PICKUP
■ HYSTERESIS
■ TIME DELAY
■ FREQ INHIBIT
■ ALARM CONFIG
● 59 OVERVOLTAGE
○ LOW LINE SF (Visible when an input is selected for the Low Line Override programmable function.)
○ 3 / 1 PHASE SETTINGS
■ PICKUP
■ HYSTERESIS
■ TIME DELAY
■ ALARM CONFIG
● 47 PHASE IMBALANCE
○ PICKUP
○ HYSTERESIS
○ TIME DELAY
○ ALARM CONFIG
○ LOW LINE SF (Visible when an input is selected for the Low Line Override programmable function.)
● 81 O/U FREQUENCY
○ UNDERFREQUENCY
■ INHIBIT VOLTS
■ PICKUP
■ HYSTERESIS
■ TIME DELAY
■ ALARM CONFIG
○ OVERFREQUENCY
■ PICKUP
■ HYSTERESIS
■ TIME DELAY
■ ALARM CONFIG
○ ALTRNT FRQ SCALE FCTR
■ ALT FREQ SF
● 50 OVERCURRENT
○ LOW LINE SF (Visible when an input is selected for the Low Line Override programmable function.)
○ 3 / 1 PHASE SETTINGS
■ PICKUP
■ TIME DELAY
■ ALARM CONFIG
