Basler DGC-2020ES User Manual

2-8 9469200995
Configuration through the Front Panel DGC-2020ES
○ WEAK BATTERY VOLTAGE
■ ENABLE
■ THRESHOLD
■ ACTIVATN DLY
○ HIGH FUEL LEVEL
■ ENABLE
■ THRESHOLD
■ ACTIVATN DLY
■ HYSTERESIS
○ ACTIVE DTC (Visible when DTC is enabled.)
■ ENABLE
○ ECU COMMS FAIL (Visible when CAN BUS is enabled.)
■ ENABLE
○ COOLANT LEVEL (Visible when CAN BUS is enabled.)
■ ENABLE
■ THRESHOLD
○ CEM COMM FAIL (Visible when CEM-2020 is enabled.)
■ ENABLE
○ CHECKSUM FAIL
■ ENABLE
○ BRK CLOSE FAIL PALM
■ ENABLE
○ BRK OPEN FAIL PALM
■ ENABLE
○ REVERSE ROTATION
■ ENABLE
• ALARMS
○ HIGH COOLANT TEMP
■ ENABLE
■ THRESHOLD
■ ARMING DELAY
○ LOW OIL PRESSURE
■ ENABLE
■ THRESHOLD
■ ARMING DELAY
○ LOW FUEL LEVEL
■ ENABLE
■ THRESHOLD
■ ACTIVATN DLY
○ OVERSPEED
■ ENABLE
■ THRESHOLD
■ ACTIVATN DLY
○ COOLANT LEVEL (Visible when CAN bus is enabled.)
■ ENABLE
■ THRESHOLD
○ CAN LOW COOL LEVEL
Note
The HIGH COOLANT TEMP and LOW OIL PRESSURE alarms have
an ARMING DLY setting that disables the alarm for the specified time
after engine startup.
● SENDER FAIL
○ COOL TEMP SENDR FAIL
■ CONFIG TYPE
■ RECOGNITION
■ ACTIVATN DLY
■ MIN OHMS
■ MAX OHMS
■ SF DISPLAY
○ OIL PRESS SENDR FAIL
■ CONFIG TYPE
■ RECOGNITION
