AW00118508000 Camera Functional Description
Basler racer Camera Link 31
Fig. 11: Camera Block Diagram
Sensor
Data
Micro-
Controller
Control
Data
Frame
Grabber
Control
Camera
Link
Interface
FPGA
Control
Camera
CC1
CC2
CC4
CC3
Image Data
Serial Port
PC
Digitized
Pixel
Data
