10
3.1.2 Tower > LCD panel
6 Button LCD Panel
Item
Sign
Description
LCD Display
Green LED steadily lights up to indicate
that the Utility input voltage is within the
window.
(In standby mode: 90Vac~150Vac)
(In Line mode: 55Vac~150Vac)
Green LED lights up to indicate there is
an output available at the Programmable
Outlet 1 & Programmable Outlet 2.
Amber LED lights up to indicate the
Bypass Input is normal.
UPS Fault LED
UPS On/Alarm Silence
UPS OFF Switch
Special functions log in/out
Go to next page
