28
GB Battipav srl
CUTTING ON THE TABLE
CAUTION
BEFORE PERFORMING THE CUTTING OPERATIONS,
MAKE SURE THAT THE MATERIAL IS PROPERLY
LEANED AGAINST THE TILE STOPPER.
CAUTION
19
BEFORE STARTING THE CUTTING
OPERATIONS, THE OPERATOR MUST MAKE
SURE THAT AT LEAST 150 cm ARE LEFT FREE
AROUND THE MACHINE (Pos. 2).
IN ORDER TO WORK IN SAFETY CONDITIONS,
DO NOT LET OTHER PEOPLE REMAIN NEAR
THE MACHINE DURING THE CUTTING
OPERATIONS.
THE OPERATOR STANDS IN THE WORKING
POSITION (Pos. 1) DURING THE DIFFERENT
MACHINE OPERATION PHASES.
20
Thanks to the great versatility of the CLASS
PLUS machine, it is possible to carry out different
types of cutting.
Position the piece which needs cutting on the
working table and make sure that it is properly
leaned against the tile-stopper. If necessary, a
bearing square can be of help.
CAUTION
THE MILLIMETRE RULER PLACED ON THE
WORKING TABLE HELPS ONLY WITH THE
CARRYING OUT OF LINEAR CUTTING.
21
In order to carry out any diagonal cutting lean
the tile against the square the way it is shown in
picture 12 and go on with the cutting operation.
CUTTING A SURFACE AT 45°
CAUTION
Before positioning the motor head, make sure that:
• the machine is off;
• the cutting tool is not moving;
22
Referring to the graded scale located on the
machine upright, move the motor head to the
JOLLY position and tighten the knobs.
With the locking lever, lower the cutting head until
placing the blade some millimetres below the table
level.
CAUTION
BEFORE ANY CUTTING MAKE SURE THAT THE TILE
TO BE CUT IS PROPERLY LEANED AGAINST THE
TILE-STOPPER.
With the CLASS PLUS machine it is also possible to
set out:
a) the cutting length with the cutting adjustment
knobs.
b) the cutting depth with the locking lever.
c) the straight cut measurement with the tile bearing
square as well as the ruler placed on the working
table.
23
In order to carry out special working it is possible
to set out any cutting inclination ranging from 0°
to 45° as marked on the machine side.
LASER MARKER
CAUTION
CLASS IIIA 635 nm, < 5 mW LASER INSTRUMENT
By means of the laser marker accessory, the cutting
operations can be accelerated.
CAUTION
THE LASER MARKER STARTS WORKING ONCE THE
MACHINE IS CONNECTED TO THE POWER SUPPLY.
