TROUBLESHOOTING
HAVE YOUR TOOL REPAIRED BY A QUALIFIED PERSON
This electric tool complies with the relevant safety rules. Repairs should only be carried out by qualied
persons using original spare parts, otherwise this may result in considerable danger to the user.
Malfunctions not related to a conformity defect that exists at the time of purchase are excluded from the
warranty. Exclusions include:
- Wear of materials (taking into account the average life of the product)
- Failure to comply with the recommendations contained in this manual.
- Maintenance and tampering carried out by unauthorized personnel.
- Use of non-original spare parts.
Faul Cause Remedy
The machine does not work. The power supply cable is damaged or
not properly connected.
Press the plug rmly into the power
socket. Check the power supply cable.
No voltage in the socket. Have the socket checked.
Control switch is damaged. Consult local dealer for replacement.
If lubrication does not arrive at the
disk with the pump running.
The sprayer unit is clogged. Dismantle the sprayer assembled inside
the disk cover and remove any possible
residuals.
Motor gives off unpleasant odour. Water may have seeped through inside
the motor
Unplug the power supply cable and
consult local dealer.
Machine is difcult to start. Motor bearings are damaged. Unplug the power supply cable and
consult local dealer.
The machine is cutting out of square. The tile supports are not at right angles
with the cutting disc.
Using a square, adjust the tile supports
to 90° in relation to the cutting line of
the disc.
The disc is not suitable for the type of
material to be cut.
Replace the disc with a more suitable
one.
The laser marker does not work. The laser unit is damaged. Contact your local dealer for a
replacement.
The marker feeder is damaged. Contact your local dealer for a
replacement.
