ALWAYS STAY IN THE WORKING POSITION
(Pos. 1 picture 19) DURING THE MACHINE
OPERATION PHASES:
• During material loading;
• During material cutting;
• During the cutting tool deceleration following the
machine stop.
MAINTENANCE
CAUTION
BEFORE PERFORMING ANY OPERATION OR
ADJUSTMENT, DISCONNECT THE MACHINE FROM
THE SUPPLY MAINS.
CLEANING
CAUTION
DO NOT WASH THE MACHINE WITH HIGH
PRESSURE WATER JETS
27
It is extremely easy to clean the CLASS PLUS
machine by loosening the side knobs and
dismantling the working table.
Through the tap located on the bottom of the
recovery tank, remove any working residual from
the machine
CAUTION
28
AFTER THE TANK CLEANING OPERATIONS,
PLACE THE WORKING TABLE BACK IN
POSITION, OBSERVING THE DISTANCE FROM
THE LEG SUPPORT.
29
30
For a greater efciency of the patented
SPRAY SYSTEM lubrication system, clean
it regularly as indicated.
CAUTION
MOTOR CARRIAGE ADJUSTMENT
The motor carriage is provided with a register for the
vertical play adjustment.
For correct adjustment, proceed as follows:
31
• with a 3 mm Allen wrench, screw both front
adjustment dowels (A), until the play is
eliminated.
32
• repeat the operation for both back adjustment
dowels (B).
CAUTION
TIGHTEN THE FOUR REGISTERS EQUALLY IN
ORDER TO OBTAIN SUITABLE SMOOTHNESS.
DISPOSAL
When parts wear out or when the machine is nally
scrapped, waste disposal must be carried out in
compliance with the laws in force.
Electric Motor
Aluminium AL
Steel AC
Copper CU
Polyamide PA
Main Body
Steel AC
Polyamide PA
Submersed pump
Polyamide PA
Steel AC
Aluminium AL
Copper CU
Epoxy Resin
The European Directive 2012/19/EU
arranges that in the event of scrapping
of electrical equipment, they must not
be disposed of city solid refusals but collected
separately, in order to optimize the level of recovery
and recycling of the materials and above all in order
to prevent damages to health and environment.
To comply with European Directive 2012/19/EU, all
electrical equipments must be marked with crossed
basket symbol.
The packing of the machine will be disposed of in
accordance with the methods laid down by current
legislation.
For further information concerning disposal
of electrical equipment, please refer to public
administration service.
