MVT26
October 2003 Section 3 Page 41
Item Qty Part No. Description Notes
◊ 1 79680 K180II 1st Stage Valve Head Assembly
1 † … 1st Stage Valve Head
2 1 N26029 Plate Valve
3 4 N16 Washer
4 4 N644 Self Locking Hex Nut
5 1 N58 Washer
6 1 N150 Allen Screw M8x60
Figure 3.1-25 K180 1st Stage Valve Head
1
2
3
4
5
6
3
4
3
4
3
4
