Bauer Compressors P5 User Manual

MNL-0096
April 17, 2013 Page 18
3.3.2 Configuration Options
On some models the P31 Purification system can be specified at the time of purchase as a factory
installed option and may not be installed on your unit.
Figure 3-5 P31 Purification System Cross Section
1. Inlet
2. Jet Pipe
3. Plug
4. Final Pressure Safety Valve
5. Housing
6. Cartridge
7. Bottom
8. Pressure Maintaining Valve
9. Safety Bore
1
2
3
4
5
4
6
7
8
9
Cartridge Removal
