Bauer Compressors P5 User Manual

MNL-0096
April 17, 2013 Page 34
4.6.4 P4 Purification System
Item Qty Part No. Description Notes
1 1 079416 Oil and Water Separator See Figure 4-23
2 1 011430 Condensate Drain Valve
3 2 VAL-0007 Check Valves
4 1 080144 27” Dryer Chamber See Figure 4-28
5 1 080143 10” Purification Chamber See Figure 4-24
6 1 VAL-0377 Bleed Valve
7 1 VAL-0053 Pressure Maintaining Valve
8 1 VAL-0169 Safety Valve
Figure 4-11 P4 Purification System
IN
OUT
1
2
345 6
3
7
8
