Bauer Compressors P5 User Manual

MNL-0096
April 17, 2013 Page 76
5.3.2.3 Cartridge Leaks after Installation
1. Remove the cartridge following steps to 3.3. in Paragraph 5.2.2.2.
2. Install cartridge if it is missing.
3. Remove cartridge and inspect O-rings.
4. Replace O-rings if necessary.
5. Ensure protective caps and devices have all been removed.
6. Replace cartridge following steps 7. to 11. in Paragraph 5.3.2.2.
Figure 5-11 Cartridge Replacement
NOTICE
If air is detected bleeding out from the bottom of the chamber, the cartridge has not been installed
properly or is missing. Follow the instructions in Paragraph 5.2.2.3.
Pull
Out
Thread
On
