MNL-0096

April 17, 2013 Page 70

Figure 5-7 (cont.) Securus

Chamber Assembly

Item Qty Part No. Description Notes

4 1 067072 Packing Sleeve

5 1 067093 Tapered Pin

6 2 N17455 O-ring

7 2 N17456 Back-up Ring

8 † … Chamber Bottom Plug Available only with 067106

9 1 059850 Socket RF Type

10 1 065500 Bleed Valve

11 1 067097 Securus

Cartridge MS/AC/MS

12 1 N15205 O-ring

13 1 067070 Sealing Cuff

14 1 N17454 O-ring

15 1 N17453 O-ring

16 1 N17457 Retaining Ring

17 2 012293 Tool Post Screw

18 † … Cover Plate Available only with 067106

19 † … Chamber Head Available only with 067106

N.S. 1 N15095 Securus

Indicator 110 - 120VAC, 50 - 60 Hz

— 1 N15096 Securus

Indicator 12 - 24 VDC
