Baumatic BAD4504 - Filter Assembly; Filtering System

11
Th e filte r pre vents la rger re mnants of food o r othe r obj ects from ge tting insi de the p ump.
Th e resi dues m ay bl ock the f ilter, in th is case t hey must be rem oved.
The fi lter system c onsists of a coar se fi lter, a flat ( Main f ilter)
And a microfilter(Fine filter).
Food and soil part icles trap ped in t his f ilter are pulv erize d b y a
s pe cial jet on the l owe r spr ay arm an d w ashed d own to d rain.
Larger ite ms, such as piec es o f bon es o r gl ass, that c ould b lock
t he drain ar e t r a pp ed i n th e c oar s e f ilter. To re move th e items
c au ght b y t he fil ter, ge ntly sque eze the tap on the to p of this
filter and lift out.
T his f ilter hold s so il an d f ood r esid ues in t he sum p a re a and
preve nts i t fro m bei ng redepo sit on t he di shes du ring wa sh cy cle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filter assembly
The fi lter e f f icientl y
Fo r best per form anc e a nd re sults, t he fil ter must be cl eane d re gula rly. t his r eas on, i t i s a goo d id ea to
remove the l arger food partic les t rapp ed i n the f ilter a fter e ach was h cy cle by rinsi ng t he s emicir cula r filte r an d
cup under running water. To remove the filter device, pull the cup handle in the upwarddirection.
removes food particles fromthewash water, allowing it to berecycled during the cycle.
Fo r
The d ishwash er m ust never be used with out the filters.
Impro per rep lacem ent of the f ilter may re duce the perfo rman ce level of the applia nce
and da mag e dis hes a nd utens ils.
Step 1 Turn the filterin anti-clockwisedirection,
the n li f t it u p.
：
Step 2 l if t t he Main f il te r up：
Step 3 lift the F ine filter up：
When following th is procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.
1
2
3
