Baumatic BAD4504 - Aesthetic Panels Dimensions and Installation

14
Minimum space when
thedoorisopened
【Figure
2】
Cabinet dimensions
【Figure1】
Less than 5mm
between the top
of dishwasher and
cabinet and the
outerdooraligned
to cabinet.
90 °
90 °
450 mm
820mm
100
580mm
80
Space between cabinet
bottom and floor
Electrical, drain and
water supply line
entrances
Cabinet
Dishwasher
Door of
dishwasher
Minimum space of 50mm
1 The aesthetic wooden panel could be processed according to the figure 3
The aesthetic panel should
be processed in accordance
with the illustrated dimensions
【Figure
3】
●
Aesthetic panel's dimensions and installation
15
444
390
418
179 175
38
