Fitting the distance limiter
IMPORTANT: The distance limiter MUST be fitted to the
appliance, to prevent it from being pushed up against
the wall surface behind it.
o Push the distance limiter in the direction shown in the diagram
above.
o Ensure that Clamp A is secured to Hole A.
o Insert Clamp B and Clamp C into their respective square holes.
Positioning
33
