o IMPORTANT: Make sure that the vent on either side of chimney
section H is pointing upwards and not inside of chimney section
G.
18) Lift chimney section H up to the fixing bracket that you secured to
the wall in step 16. Secure it to the fixing bracket using the screws
provided. Make sure that these screws are fully tightened.
o If you are installing the appliance at its minimum height, then
you should connect chimney section G to the fixing bracket.
Electrical connection
The electrical connection must correspond to the electrical requirement
noted on the rating plate, which is placed inside of the cooker hood.
The appliance should be connected to the electrical supply. See pages
16 – 17 for detailed information on the electrical connection.
Refit the grease filters and then switch on the mains
supply to the appliance. Press the ON/OFF button and
check that the appliance is operating correctly.
26
