Baumer NE215 - Programming Plan; Status and Operating Mode Programming; Scaling Factor and Frequency Programming; Reset and Output Time Programming

32
NE215
7.10 Programming plan
Lines in
italic* = Factory setting
Line 11-18 Status for line 11-18
0 * Parameter can be changed
1 Clearing and/or input disabled
2 Parameter is skipped
Line 21 Operating mode principal count system
0 * Progressive preselections
1 P1 Trailing preselection
Line 22 Not applicable
Line 23 Scaling factor batch counter
00 Minimum value
1 * Default value
99 Maximum
Line 24 Not applicable
Line 25 Not applicable
Line 26 Frequency batch counter counting
0 * 10 kHz
1 25 Hz
2 15 Hz
Line 27 Not applicable
Line 28 Not applicable
Line 29 Not applicable
Line 30 Reset batch counter
0 * Autom. reset and external static
1 Autom. reset and external differential
2 External static
3 External differential
Line 31 Output time P1, (P2), (P3), B1
00.00 Maintained contact (LAtcH displayed)
0.25 * Default value
99.99 Maximal value
Line 32 Output time P1, (P2), (P3), B1
00.00 Maintained contact (LAtcH displayed)
0.25 * Default value
99.99 Maximal value
Line 33 Output time P1, (P2), (P3), B1
00.00 Maintained contact (LAtcH displayed)
0.25 * Default value
99.99 Maximal value
Line 34 Take-over of preselection P1, P2, B1
0 * In case of reset
1 After input
Line 35 Address for function key
0 * Function key not connected
:
8 Maximum value
Open interface description
