10.5 Optical data
Laser
Wavelength 650nm - 680 nm (visible red)
Pulse frequency 50 kHz
Duty cycle 50%
Average power < 0.5 mW
Laser class 2 (to IEC 60825-1 / 2007)
Beam diameter
FLDK110x1003/Sxx
at emission point about 2.5 mm
40 mm beneath sensor Line focus, 2 mm long, perpendicular to the Scatec housing
FLDK110x1005/Sxx
FLDK110x1006/Sxx
at emission point about 2.5 x 4 mm
100 mm beneath sensor Line focus, 3 mm long, perpendicular to the Scatec housing
Focus position
FLDK110x1003/Sxx 40 mm beneath sensor
FLDK110x1005/Sxx 100 mm beneath sensor
FLDK110x1006/Sxx
Optical receiver equipped with NIR suppression filter and
daylight suppression filter
10.6 Application data
Measuring range
FLDK110x1003/Sxx 0 to 60 mm beneath sensor
FLDK110x1005/Sxx 0 to 120 mm beneath sensor
FLDK110x1006/Sxx
Mounting height
FLDK110x1003/Sxx 40 mm above conveyor
FLDK110x1005/Sxx 100 mm above conveyor
FLDK110x1005/Sxx
Object speed 2 m/s maximum (5 m/s maximum for thicker edges)
Minimum object spacing 10 mm @ v = 1 m/s and output pulse length 10 ms, or
proportional to the speed and output pulse length
Counting rate 600,000 maximum copies/h
Product orientation Fold facing laser beam
Output pulse length 5, 10, (15, 20) ms selected by DIP switch
Dead time 0 ms with inactive false pulse suppression, otherwise 18%
of the average product spacing time
Pulse issue time
FLDK110x1003/Sxx at the end of the edge
FLDK110x1005/Sxx at the beginning of the edge
FLDK110x1006/Sxx depending on the selected running direction
