Electrical data
Instruction handbook BUM 60 / BUS 60
Document No.: 5.01032.05 Baumüller Nürnberg GmbH
28
of 82
3.4
1)
Single-phase connection possible. Voltage difference between phases must not exceed +/- 3,0 %
2)
All nominal values refer to a connection voltage of 400 V
With a single-phase connection, the rated DC link voltage is reduced by 35 %
3)
With a single-phase connection, the value is reduced by 66%
4)
With a single-phase connection, the value is reduced by 50%
5)
The current information depends on the controller type
Digital controller: effective value for sinus commutation
6)
For a maximum of 200 ms without preloading using E/V-controller
For a maximum of 1 s without preloading using V-controller
The load cycle must be dimensioned, that the effective value of the output current does not exceed the rated current.
7)
If UL508C has to be observed: the external ballast resistor must protect itself from overheating.
8)
Do use fuses, which have a I
2
t-value at the working point of max. 510 A
2
s .
If UL508C has to be observed: do use fuses 32A/1000V: 3NE4 101 manufactured by Siemens (Item-No. 101 940 Baumüller). The cor-
responding fuse-carrier is available from Baumüller (Item-No. 101 960). You may even use UL-approved fuses listed in the table below.
In the table below we have listed UL-approved fuses and fuses that are not UL-approved. Please observe, that the listed fuses are of
different design and that you have to use corresponding fuse-carriers. Not all fuses listed below can be inserted into the above listed
fuse-carrier from Baumüller!
Bussmann 00 16A/690V: 170M2692 20A/690V: 170M2693 25A/690V: 170M2694 32A/690V: 170M2695
40A/690V: 170M2696
Gould 0 40A/690V: A0-69E40 D8 50A/1250V: A0-125E50 D1
SIBA 00 16A/690V: 2047734-16 20A/690V: 2047734-20 25A/690V: 2047734-25
Siemens 000 16A/690V: 3NE1 813-0 20A/690V: 3NE1 814-0 25A/690V: 3NE1 815-0
00 20A/660V: 3NE8 714 25A/660V: 3NE8 715 25A/660V: 3NE8 015 25A/690V: 3NE8 015-1
32A/660V: 3NE8 701 35A/660V: 3NE8 003 35A/690V: 3NE8 003-1
0 32A/1000V: 3NE4 101 40A/1000V: 3NE4 102
size
bold: no UL
Full range fuses (semiconductor and line protection)
9)
The output voltage is a pulse-commutated DC. The setting range refers to the r.m.s. value of the fundamental wave.
10)
R.m.s. value at an ambient temperature of 45 °C.
11)
The rated output current must be reduced between 45 °C and 55 °C. The rated output current is calculated according the following
formula::
I
A
I
A45°C()
1
environmental temperature 45°C–
°C
------------------------------------------------------------------------------------------------– 003,⋅
⎝⎠
⎛⎞
⋅=
For example: rated output current = 30 A, environmental temperature = 47° C:
I
A
30A 1
47°C45°C–
°C
--------------------------------- -
003,⋅
⎝⎠
⎛⎞
–
⎝⎠
⎛⎞
⋅ 30A 0 94,⋅==
The output current must be reduced to: 28,2 A
12)
A minimum break time after switch-off of 2 min.must be observed.
